Cincinnati 340-20 Twin Grip Centerless Grinder

Out of Stock

Stock Number #S-1881

  • BrandCincinnati
  • Model340-20
  • Equipment TypeTwin Grip Centerless Grinder

Overview


Cincinnati 340-20 Twin Grip Centerless Grinder
Model: DE
Serial Number: 350520H81-0004

CATALOGUE SPECIFICATIONS:
Work Diameter Capacity Maximum (With New Wheel)…….. 6″
Work Diameter Capacity Nominal……………………. 1/2″ to 3″
Grinding Wheel Diameter, Maximum………………….. 24″
Grinding Wheel Diameter, Minimum………………….. 16″
Grinding Wheel Width, Maximum…………………….. 20″
Grinding Wheel Width, Minimum…………………….. 1″
Grinding Wheel Hole Diameter……………………… 12″
Regulating Wheel Diameter, Maximum………………… 14″
Regulating Wheel Diameter, Minimum………………… 10.25″
Regulating Wheel Width, Maximum…………………… 20″
Regulating Wheel Width, Minimum…………………… 1″
Regulating Wheel Hole Diameter……………………. 6″
Regulating Wheel Speeds (Variable)………………… 11 – 300 RPM
Grinding Wheel Motor…………………………….. 40¬†HP
Regulating Wheel Motor…………………………… 2 HP
Hydraulic System Motor…………………………… 2 HP

EQUIPPED WITH:

20″ Thru-Feed Workrest
6″ Diameter Regulating Wheel Spindle
Outboard Bearing Support On Grinding & Regulating Wheel Spindles
Hydraulic Profile Grinding Wheel Truing
Hydraulic Profile Regulating Wheel Truing
Free Standing Electrical Panel

Approximate Machine Dimensions……………………. 114″ x 158″
Approximate Machine Height……………………….. 96″
Approximate Machine Weight……………………….. 28,000 LBS

This item was recently sold.
Looking for a similar machine?

OR

Call for more information 586-465-9700

Financing is available upon request.
