Cincinnati Milacron 230-10 Twin Grip Centerless Grinder

Overview

Cincinnati Milacron 230-10 Twin Grip Centerless Grinder
Model 230-10 Twin Grip
Serial Number:

SPECIFICATIONS:
CAPACITY
Standard thru feed & infeed work rests: 1/4″ to 4″ dia.

WHEELS
Grinding wheel: widths up to 10″, 12″ hole, 24″ dia.
Regulating wheel: widths up to 10″, 5″ hole, 12″ dia.
DRIVE
Grinding wheel drive: 30 HP

SIZING ADJUSTMENT
hand wheel graduated in: .000050″
Fine & Coarse Push Button Compensation

WHEEL TRUING EQUIPMENT
Grinding wheel
Hydraulic wheel profile diamond truing unit with auto diamond advance.
Regulating wheel
Hydraulic profile regulating wheel truing unit.
Diamonds are not included as standard equipment.

EQUIPPED WITH:
Thru-Feed Workrest
Attached Electrical Panel

Regulationg Wheel Head Completely Rebuilt in 2020

FLOOR SPACE
Standard machine: 95″ x 127 1/2″
APPROXIMATE WEIGHTS & DATA
Net weight: 18,000 lbs.
