HAAS VF-0 CNC Vertical Machining Center

Out of Stock

Stock Number #2011

  • BrandHAAS
  • ModelVF-0
  • Serial Number13254
  • Year1998
  • ConditionExcellent
  • Equipment TypeCNC Vertical Machining Center

Overview


HAAS VF-0 CNC Vertical Machining Center

SPECIFICATIONS:
X Axis Travel: 20″
Y Axis Travel: 16″
Z Axis Travel: 20″
Rapid Rate X Axis: 710 IPM
Rapid Rate Y Axis: 710 IPM
Rapid Rate Z Axis: 710 IPM
Table Size: 26″ x 14:
Max Table Load: 1,500 LBS
Spindle Motor: 20 HP
Spindle Speed: 10,00 RPM
Spindle Taper: 40 CT
Tool Changer: 20 ATC
Cutting Feed Rates: 500 Inch Per Minute
Spindle Nose to Table (Min.- Max.): 4? – 24?
Dimensions: 92″ x 95″ x 95″
Weight: 7,500 LBS

EQUIPPED WITH:
HAAS CNC Control – Updated in 2019
3000 Spindle Hours
Misc CAT 40 Tool Holders
4th Axis Plug In
Table Vise
3 Jaw Chuck for Table
Coolant Tank & Pump
Manuals & Drawings

Videos


This item was recently sold.
Looking for a similar machine?

OR

Call for more information 586-465-9700

Financing is available upon request.
