Studer S145 CNC Internal Grinder

Out of Stock

Stock Number #2192

  • BrandStuder
  • ModelS145
  • Year2000
  • ConditionGood - Used
  • Equipment TypeCNC Internal Grinder


Studer S145 CNC Internal Grinders with
4-Heads, 24K and 120K Wheel Head

CNC Control: Fanuc 16i-TB
Capabilities and Features: C-Axis for form & thread grinding / Q-Axis for Swivel of head / 4-Position Internal Grinding Spindles
Workpiece Envelop: 19.700″ x 4.700″
Z-Axis Travel: 19.700″
X-Axis Travel: 4.700″
ID Grinding Diameter(s): Max. 11.811″
ID Grinding Depth: 4.700″
Max. Swing over Bed: 13.800″
Center Height: 7″
Number of Programmable Grinding Spindles: 4 ID Spindles
Spindle Speeds: 24,000 RPM to 120,000 RPM
Angle Adjustment on Wheel Head:: 0.000 degrees
OD Grinding Wheel Dimensions: 10″ x 1″
Workload: 176 Lbs.

  •         Control: GE Fanuc 16i-TB
    Turret-type wheelhead with 4 tool positions for internal grinding spindles
  • Q-axis with a swivel range of +/-30 deg
  • Frequency-controlled internal grinding spindles
  • C-axis for the workhead for form and thread grinding
  • Large selection of multi-range spindles
  • Full enclosure with sliding door
  • Machine base made of Granitan
  • Standardised interface for loader and peripheral devices
  • Extensive range of chucks and accessories
  • Manuals & Prints


This item was recently sold.
Looking for a similar machine?


Call for more information 586-465-9700

Financing is available upon request.
