Toyoda GE4P-50 CNC Plain OD Grinder

  |   By  |  0 Comments

12.6″ x 20″ toyoda ge4p-50m cnc plain cylindrical grinder
new: 2013

SPECIFICATIONS:
max. work swing: 12.6″
max. distance between centers: 20″
max. supportable weight: 330 lbs.
workhead
work speeds, infinitely variable: 10 – 500 rpm
center taper: #4 morse
workhead spindle: live spindle
wheelhead
travel distance: 9.843″
rapid traverse rate: 393.7″ inch/min
programmable feed rate: 0.00001 – 200 inch/min
straight: 0 degrees fixed
wheel spindle bearings: toyoda stat bearings
tailstock
work center taper: #4 morse
quill travel distance: 0.787″
taper compensation: 0.002
quill advance/retraction: hydraulic power
grinding wheel
size (od x width x id): 16″ x 3″w x 5″
max. grinding wheel width: 4″
minimum grinding wheel o.d.: 11″
sfpm surface speed: 6,500 – 4,475 sfpm
table
travel distance: 30.315″
rapid-traverse rate: 393″ inch/min
programmable feed rate: 0.0001″ – 200″ inch/min
swivel of taper adjust: 0 to 12.5 degrees
way construction: ground, vee and flat pressurized
motors
wheel spindle: 5 hp t.e.f.c.
work spindle: 1.0 hp ac servo
wheelhead feed motor: 1.15 hp ac servo
table feed motor: 1.75 hp ac servo
wheel spindle lube: 1/3 hp
machine dimensions and construction
dimensions: 58″w x 76″d x 74″h
centerline of workpiece, height from floor: 41″
weight: 8,800 lbs.
construction: cast iron

tank capacities
way lubrication oil tank: 3.17 gallons
wheel spindle lubrication tank: 3.17 gallon
lubrication
wheel spindle: recirculating hydraulic oil
ways: recirculating lube oil
ballscrews: recirculating lube oil
workhead spindle: permanent grease packed
footstock: recirculating hydraulic oil
electrical specifications
standard voltage: 220 volts, 3-phase, 60 hertz, ac
toyoda rc-50b cnc control specifications:
manual pulse generator
full linear and circular contouring and positioning
digital and ac servo systems
direct rpm programming or constant surface feet per minute
built-in diagnostics
color lcd display
macro subroutines
decimal point programming
absolute/incremental programming
usb port, computer interface
machine features & equipment
cast iron machine base
vee & flat pressurized way system
combination live & dead spindle workhead
workhead, dual “live” & “dead” spindle option
toyoda “stat” grinding wheel spindle bearings
hydraulic power operated tailstock
fine taper adjustment of tailstock
presently has a 16″ x 3.5″w grinding wheel, with 4″ wheel guard capa
coolant system with “barnes” magnetic separator
dial indicator for table swivel adjustment
center in workhead

KIA KBN 135 CNC Horizontal Boring Mill

  |   By  |  0 Comments

KIA KBN 135 CNC Horizontal Boring Mill
Serial Number: KBN1350017
New: 1999

SPECIFICATIONS:
X-Axis Travel: 118.1″
Y-Axis Travel: 78.7″
Z-Axis Travel: 63″
Spindle Speed: 2,000 RPM
Spindle Taper: CAT 50
Spindle Motor: 30 HP
Tool Magazine Capacity: 40 ATC
Control: Fanuc 16i
Chip Removal: Chip Conveyor
Coolant: 1,000 PSI CoolJet Through Spindle Coolant
Table Size: 78.74” X 70.87”
Table Load Capacity: 22,046 LBS.
Spindle Diameter: 5.3″
W – Axis Travel: 27.6″
B – Axis Indexing: .001
Tool Diameter: 5.1″, 9.8″
Tool Length: 23.6″
Tool Weight: 66 LBS.
Rapid Traverse X, Y, Z, W: 315, 315, 315 IPM
Cutting Feed Rate: .04 ~ 197 IPM
Machine Weight: 82,012 LBS

4th Axis Rotary Table
60 + Tool Holders
Misc. Table Fixtures
Misc Inspected & Calibrated Every Year w/ Reports Available

Machine Installed into current location 2015.  New Drives and Fully Maintenance

Haas GR 510 CNC Router

  |   By  |  0 Comments

Haas GR 510 CNC Router

Table Size: 122″ x 53″
X-Axis Travel: 121″
Y-Axis Travel: 61″
Z-Axis Travel: 23″
Spindle Speed: 10,000 RPM
Spindle Motor: 20 HP
Spindle Taper: CT-40
Automatic Tool Changer: 20 Station
Electrical Requirements: 460 V; 3 Ph

EQUIPPED WITH:
Haas CNC Control
USB Interface
14″ Risers
20 Position Tool Changer
Coolant Tank
Unist Cooling System
Tool Probe

Rollmatic CNC Tool Grinding Machine

  |   By  |  0 Comments

Rollmatic CNC Tool Grinding Machine
Model CNC 148 P4
Serial Number: 4493
Year: 2005

SPECIFICATIONS:
Grinding capacity Ø 0.025 -12.7 mm
Grinding length 0 – 200 mm
Bar diameter Ø 1.0 – 12.7 mm
Motor 0.70 KW
Rotation 300-3000 rpm
Dimensions 1830 x 2040 x 2100 mm
Weight 1800 Kg

Y-Axis has a little slop per Customer

HAAS GR 512 CNC Router

  |   By  |  0 Comments

HAAS GR512 CNC Router

SPECIFICATIONS:
Travels:
X Axis 145″
Y Axis 61″
Z Axis – 11″
Spindle Nose to Table (Max.) 13.5″
Spindle Nose to Table (Min.) 2.5″
Table:
Length 144″
Width 60″
Thickness 1″
Between Columns 62″
Max. weight on table (evenly distributed) 6000 lbs

Spindle:
Max. Rating 15 HP
Max. Speed 10,000 RPM
Max. Torque 17 ft-lb @ 4600 RPM
Drive System (Direct Speed) Belt Drive
Taper CT 40

FeedRates:
Rapids on X 800 in/min
Rapids on Y 2100 in/min
Rapids on Z 1100 in/min
Max. Cutting 800 in/min

Axis Motors:
Max. Thrust X 2520 Lb
Max. Thrust Y 1020 Lb
Max. Thrust Z 2050 Lb

Tool Changer:
Type Carousel
Capacity 20
Max. Tool Diameter (Full) 3.5″
Max. Tool Weight 12 Lb

General:
Air required 4 scfm, 100PSI
Coolant Capacity
EQUIPPED WITH:
Haas CNC Controls
5’x12″ Table
10,000 RPM 40 Taper Spindle
20 Position Automatic Tool Changer
Hard Disk Drive and Ethernet Interface
VISUAL QUICK CODE PROGRAMMING
RIGID TAPPING

HAAS VF-6 CNC Vertical Machining Center

  |   By  |  0 Comments

HAAS VF-6 Vertical CNC Machining Center
Model: VF-6/40
Serial Number: 1162284
New: 04/2019

Table:
Table Size: 64″ x 28″
Maximum Table Load: 4,000 lbs.

Travels:
X-Axis Travel: 64″
Y-Axis Travel: 32″
Z-Axis Travel: 30″

Spindle:
Spindle Speeds Minimum – Maximum: 10,000 RPM
Spindle Taper: CT 40 Taper
Main Motor (30 min. / cont.): 30 / 20 HP

Tool Changer:
Tool Changer Positions: 24 ATC

Rapids:
Rapid Traverse (XY/ Z): 540 / 600 IPM
Feed Rate: 0.1 – 300 IPM

General:
Floor Space (D x W x H): 159″ x 156″ x 129″
Weight: 22,000 lbs
220 V / 3 / 60

Equipped With:
Coolant Through Spindle (300 psi)
Macros
Rotation and Scaling
Rigid Tapping
M19 Spindle Orientation
High Speed Machining
VPS Editing
Media Display
1 GB Memory
Wireless Networking
Compensation Tables
Max Spindle Speed: 10,000 RPM
30 HP Vector Drive, Inline Spindle
Linear Scales
Through Tool Air Blast
Auxiliary Coolant Filter
24+1 Side-Mount Tool Changer
Chip Auger
Programmable Coolant Nozzles
Color Remote Job Handle
Power-Failure Detection Module
15″ Color LCD Monistor
USB Port
Memory Lock Keyswitch
Rigid Tapping
95 Gallon Floor Coolant System

HAAS VF-0 CNC Vertical Machining Center

  |   By  |  0 Comments

HAAS VF-0 CNC Vertical Machining Center

SPECIFICATIONS:
X Axis Travel: 20″
Y Axis Travel: 16″
Z Axis Travel: 20″
Rapid Rate X Axis: 710 IPM
Rapid Rate Y Axis: 710 IPM
Rapid Rate Z Axis: 710 IPM
Table Size: 26″ x 14:
Max Table Load: 1,500 LBS
Spindle Motor: 20 HP
Spindle Speed: 10,00 RPM
Spindle Taper: 40 CT
Tool Changer: 20 ATC
Cutting Feed Rates: 500 Inch Per Minute
Spindle Nose to Table (Min.- Max.): 4? – 24?
Dimensions: 92″ x 95″ x 95″
Weight: 7,500 LBS

EQUIPPED WITH:
HAAS CNC Control – Updated in 2019
3000 Spindle Hours
Misc CAT 40 Tool Holders
4th Axis Plug In
Table Vise
3 Jaw Chuck for Table
Coolant Tank & Pump
Manuals & Drawings

HAAS ST20 CNC Turning Center

  |   By  |  0 Comments

HAAS ST-20 CNC Lathe

SPECIFICATIONS:
2 AXIS
Swing: 31.75″
Turning: 15″ x 20.5″ Max Capacity”
Chuck Size: 8.3″ Hydraulic
Bar Capacity: 2″
Spindle Nose: A2-6
Spindle Speed: 4,000RPM
Main Motor: 20HP
Turret Capacity: 12 Stations
Rigid Tapping
Chip Conveyor
220V Electrics

(1) Owner – Replacing with a New smaller machine
Power On Time: 1982 Hours
Cycle Start Time: 1899 Hours
Feed Cutting Time: 1496 Hours

Southwestern Industries Proto Trak DPM2 Vertical Mill

  |   By  |  0 Comments

SWI Proto Trak Vertical Milling Machine
Model: DPM2
Serial Number: 062CR14525

SPECIFICATIONS:
9″ x 49″ Table
Travels: 32″ x 16″
Z Axis Travel: 27″
Max Quill Travel: 5″
Max Work Weight: 1320LBS.
3HP Head
Taper: R8

EQUIPPED WITH:
Proto TRAK SMX 3 Axis CNC Control – Conversational & G Code Programming
Torque-Rite Power Draw Bar
Coolant
220/3/60 Electrics



Dahlih DMC-2216 CNC Double Column Vertical Machining Center

  |   By  |  0 Comments

Dahlih Double Column Vertical Machining Center
Serial Number: 3006040070
New: 2019

SPECIFICATIONS:
Table Size: 2200mm x 1500mm
Travels: X Axis 2200
Y Axis 1600mm
Z Axis 800mm ( 1100mm )
Between Column: 1700mm
Feed Rate – Rapid: X Axis 20 m/min
Y Axis 20 m/min
Z Axis 20 m/min
Spindle Taper: BT50
Spindle Speed: 10,000RPM
ATC: 40 Tools
Chip Conveyor
480V / 60C / 3P

CONTROL:
Fanuc Series 0i-MF
9330 Power on Hours at time of Inspection
