HEADSTOCK SWIVEL …………………… 0 TO 90 DEG.
INFINETLY VARIABLE HEADSTOCK SPINDLE
SPEEDS ………………………….. 50 TO 450 RPM
DEAD CENTER SPEEDS …………………. 20 TO 225 RPM
HOLE THRU SPINDLE ………………….. 1- 1/4″
HEADSTOCK CENTER TAPER ……………… #6 JARNO
TAILSTOCK CENTER TAPER ……………… #6 JARNO
APPROX. DIMENSIONS …………………. 91″L X 48″D X 65″H
APPROX. MACHINE WEIGHT ……………… 3,000 LBS.
EQUIPPED WITH:
SWING-AROUND INTERNAL GRINDING ATTACHMENT WITH A P-M I.D. SPINDLE
PARKER-MAJESTIC SUPER-PRECISION SPINDLE FOR WHEELHEAD
MACHINE PRESENTLY HAS A 12″ DIAMETER x 1″ WIDE WHEEL, “NORTON” No. 32A80-KVBE
PARKER-MAJESTIC MODEL No. 3090 WORKHEAD, S/N: 59686
ELECTRONIC INFINITLEY VARIABLE SPEED CONTROL FOR WORKHEAD
SPINDLE SPEEDS
VARIABLE SPEED ELECTRIC TABLE DRIVE FOR QUIET & SMOTH OPERATION
TABLE SINE OPTION FOR ACCURATE TAPER GRINDING
TEFLON COATED LONGITUDINAL WAYS
LIVE/DEAD WORKHEAD SPINDLE
RIGID DEAD CENTER DRIVE
WORKHEAD ACCEPTS 5C COLLETS
8″ DIAMETER “BUCK FORKHARDT” 4-JAW CHUCK
.00005″ CROSS FEED DIAL GRADUATIONS
5″ BUILT-IN WORKHEAD SINE BAR
COOLANT SYSTEM, SELF-CONTAINED, IN THE BASE OF THE MACHINE
“BIJUR” ONE-SHOT LUBRICATOR
1 H.P./3/60/230-460 VOLT MOTOR FOR THE WORKHEAD
3 H.P./3/60/230-460 VOLTS MOTOR FOR THE GRINDING WHEELHEADS
MACHINE IS PRESENTLY WIRED FOR 3/60/460 VOLTS
INSPECT UNDER POWER
EXCEPTIONAL CONDITION & APPEARANCE – ORIGINAL PAINT
Brown & Sharpe No 1 Universal OD Grinder
Serial Number: 521-1-117
10″ x 24″
Left & Right grinding wheels
Table mount dresser
ID Spindle housing
Attached electrical
COMPLETE WITH:
Coolant pump and tank
All necessary motors and controls
I.D. Spindle attachment with spindle
(1) Back rest
Included: (1) Step-up 3-phase transformer for use with 220/3/60 power
Machine is wired 440/3/60
22” x 120”cc SMITHSON Universal Cylindrical Grinder
Model: 3000MM
New 1990(Approx)
22” Swing Over Table
120″ Between Centers
Hydraulic Table Traverse
Swivel Table for Taper Grinding
Variable Speed Workhead
5 HP Wheel Head Motor
20” Wheel Guard Capacity
Coolant System
440 Volt Electrics
18″ x 72″ Cincinnati Universal Cylindrical Grinder
New 1970’s RE- conditioned 2004
18″ Swing over table
72″ Between centers
16″ Diameter wheel guard
(2) 2 point steady rests
Self contained coolant pump & tank
Head stock Live / Dead centers
Hand operated tailstock
Rapid wheel slide feed in and out.
Hydraulic table travel , with pick feed at reversal
Head stock collet attachment
Landis 14″ x 48″ R Universal Cylindrical Grinder ( ID Attachment Available )
Serial Number: 796-76
New: 1984
SPECIFICATIONS:
14″ Swing
48″ Between Centers
Live & Dead Center Headstock
Auto Plunge Cycle
Tarry left & right
Pick feed L LR R
Bijur one shot lube
Manual tailstock
Attached electrical
5 HP grinding wheel motor
14″ Diameter Grinding Wheel
Self Contained Coolant Tank & Pump
(2) Steady Rests
(1) Center Rest
Table Mounted Dresser
Sony Digital Read Out
Brown & Sharpe #1 Universal Cylindrical Grinder
OD / ID Swing Down
Serial Number: 521-1-327
Pick Feed L & R
Dwell
Variable Table Speed
Variable Headstock Speed
Headstock Jog Button
Manual Tailstock
Coolant in Base
Attached Electrical Panel
220/3/60
Serial # 2U3U5K-1
Wheelhead swivel left / right center: 90 degrees
Maximum distance between centers: 72″
Maximum swing over table: 14 15/16″
Grinding Wheel diameter: 18″, 5 HP motor
Table traverse infin variable, speeds: 3 – 220 IPM
Hand table traverse per Rev / Handwheel: Rapid 15/16″ Slow 0.2″
Cross feed auto infeed / table revers: 0.0002″ – .0005 low : .005″ – .0125″ high
Cross feed wheelhead / per handwheel: 0.50″ low / .250″ high
Minimun infeed on diameter: 0.00005″
Headstock motor: 1 HP
Taper hold in spindle: # 9 B & S
Work head speeds: 50 – 500 RPM
Spindle nose: # 5 Amer stand
Headstock swivel toward / away: 90 degrees / 30 degrees
Dimensions: 20’L x 6″W
Weight: 15,000 LBS
Equipped with:
Full Hydraulic operation, hydraulic table reverse
“Acrafeed” dual rate (coarse & fine feeds) plunge infeed system
Pick feed (auto infeed), rapid wheel head advance & retraction
Right / Left table tarry
Work Light
Coolant System
Re-Alignment- Table and subtable reground, rescraped to bed ways.
Re-Aligned headstock and tailstock to proper center heights.
Rebuilt Hydraulic pump, cleaned and flushed lubrication system to ways.
New Headstock Drive Motor
Parker Majestic 1C CNC Universal OD Grinder
Allen Bradley 9/Series Control
12″ Swing
Siemens Servo Drives
2HP Spindle Drive
Sine Bar on Headstock
Work done 1997
Euchner & Heidenham Scales
Manuals
